JR510 is an Octa-core LTE Smartphone SoC launched by JLQ Technology with a balance of excellent performance and low power consumption. It has powerful image and AI processing performance, which can meet the needs of diverse applications in the mobile era, and enable mobile products more intelligent to benefit more customers.
JR510 is an Octa-core LTE Smartphone SoC launched by JLQ Technology with a balance of excellent performance and low power consumption. It has powerful image and AI processing performance, which can meet the needs of diverse applications in the mobile era, and enable mobile products more intelligent to benefit more customers.
Smooth Performance , Power Balanced
Upgraded AI Processor, Excellent Multimedia Performance
Global Communication
Multi - mode 4G LTE Modem
Support LTE Cat4 or Cat7DL/
Cat 13 UL
Support WCN: 802.11 b/g/n/ac,
BT5.0,FM
Support GNSS: GPS/Glonass/BeiDou/
Galileo/QZSS/SBAS
Perpheral Interface
Process 11nm FinFET
Modem LTE Cat 4 / 7
CPU 4*A55@2.0GHz, 4*A55@1.5GHz
GPU ARM Mali G52 2EE MC01
vDSP HW DSP
AI HW NPU 1.23Tops
Display FHD+ 60fps (21:9), HDR
Camera 25MP(13+13MP/13+13+5MP)
Video 4K 30fps Dec / 1080P 60fps Enc, HDR
Memory 2*16 LPDDR4x@1866MHz, up to 6GB
WCN 802.11 a/b/g/n/ac, Bluetooth 4.2/5.0, FM, GNSS
Storage eMMC5.1, UFS2.1
Package 12.6mm*11.8mm
Process 11nm FinFET
Modem LTE Cat 4 / 7
CPU 4*A55@2.0GHz, 4*A55@1.5GHz
GPU ARM Mali G52 2EE MC01
vDSP HW DSP
AI HW NPU 1.23Tops
Display FHD+ 60fps (21:9), HDR
Camera 25MP(13+13MP/13+13+5MP)
Video 4K 30fps Dec / 1080P 60fps Enc, HDR
Memory 2*16 LPDDR4x@1866MHz, up to 6GB
WCN 802.11 a/b/g/n/ac, Bluetooth 4.2/5.0, FM, GNSS
Storage eMMC5.1, UFS2.1
Package 12.6mm*11.8mm
